CNC ROTARY TABLE SPECIFICATIONDownload MODEL KX125 KX155 KX175 KX215 KX265 KX335 KX415 KX515 KX630 Table Diameter(mm) Ø125 Ø155 Ø175 Ø215 Ø265 Ø335 Ø415 Ø515 Ø630 Centre Bore Diameter(mm) Ø40 Ø40 Ø40 Ø60 Ø60 Ø100 Ø100 Ø100 Ø100 T-Slot size(mm) 10H7 10H7 10H7 12H7 12H7 14H7 14H7 14H7 14H7 Tenon Slot size (H7)(mm) 14 14 14 14 18 18 18 18 22 Diameter of through hole(mm) Ø30 Ø30 Ø30 Ø55 Ø50 Ø110 Ø90 N/A Ø60 Table Centre height(mm) 1:90 105 135 145 165 215 235 315 325 Speed reduction ratio 1:90 1:90 1:90 1:90 1:120 1:144 1:180 1:144 1:144 Speed (Motor 3000 rpm) 33 33 33 33 25 20.83 16.66 13.88 11.1 Horizontal position 100 100 200 300 350 600 750 900 2200 Load capacity (Kg) Vertical Position 60 60 100 150 180 250 N/A N/A N/A Vertical Position with 100 100 200 300 350 600 750 900 2200 Clamping Torque 5 bar (pneumatic) 150 150 150 250 400 N/A (Nm) 30 bar (Hydraulic) 250 250 250 500 600 1100 2000 2750 3500 Driving Torque (Nm) 150 150 150 250 400 660 800 1000 1800 Indexing accuracy ±20” ±20” ±15” ±15” ±15” ±15” ±15” ±15” ±15” Indexing repeatability ±4” ±4” ±4” ±4” ±4” ±4” ±4” ±4” ±4” Concentricity of center hole (mm) 0.02 0.02 0.02 0.02 0.02 0.02 0.02 0.02 0.02 Table run out (mm) 0.02 0.02 0.02 0.02 0.02 0.02 0.02 0.02 0.02 Net weight 39kg 40kg 45kg 65 kg 100 kg 205kg 225kg 475 kg 680 kg Name* Email* Phone* State*SubmitReset cnc Rotary Table Pictures
